Model 1022-5k Single-Point Aluminum Load Cell
Discover the Model 1022-5k Single-Point Aluminum Load Cell by Tedea-Huntleigh. Available in 5-30 kg, with low profile, IP66 rating, OIML R60 & NTEP certifications. ATEX certified, perfect for counting and grocery scales with high accuracy.
Price range: $131.99 through $152.78
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model 1022-5k Single-Point Aluminum Load Cell
Brand :- Â Tedea-Huntleigh
DESCRIPTION
The Model 1022 is a low profile single-point load cell designed for direct mounting in low cost weighing platforms.
Its small physical size, combined with high accuracy and aluminum construction, makes this low cost load cell ideally suited for retail, bench and counting scales.
Using Model 1022 load cells simplifies scale construction, which results in significant parts and labor savings.
High impedance makes this model uniquely suitable for battery operated scales.
The Model 1022 is available in a range of capacities: 5 to 30 kg, Approved to OIML and NTEP standards (pending). Environmental protection to IP66 is provided as standard. For hazardous environments, ATEX, FM and IECEx approvals available.
FEATURES
• Capacities: 5–30 kg
• Only 22 mm high
• Aluminum construction
• Single-Point Aluminum Load Cell
• Single-point 350 x 350 mm platform
• IP66 protection
• OIML R60 and NTEP approved (pending)
• Optional
– ATEX, FM and IECEx approvals available
– Symmetric configuration available
APPLICATIONS
• Bench scales
• Counting scales
• Grocery scales
