Model 1040/1041 Low Capacity Single-Point Aluminum Load Cells
Discover the Model 1040/1041 Low Capacity Single-Point Aluminum Load Cells by Tedea-Huntleigh. OIML R60 & NTEP approved, FM certified, and IP65 rated. Ideal for bench, counting, and grocery scale applications with low capacity (5-100 kg) accuracy.
Price range: $53.69 through $143.06
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model 1040/1041 Low Capacity Single-Point Aluminum Load Cells
Brand :- Tedea-Huntleigh
DESCRIPTION
The Models 1040 and 1041 are low profile single-point load cells designed for direct mounting of low cost weighing platforms.
Their small physical size, combined with high accuracy and low cost, makes these load cells ideally suited for retail, bench and counting scales.
Available in anodized aluminum, these high accuracy load cells are approved to NTEP and other stringent approval standards, including OIML R60. An optional special humidity resistant protective coating assures long-term stability over the entire compensated temperature range.
The two additional sense wires feed back the voltage reaching the load cell. Complete compensation of changes in lead resistance due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics.
FEATURES
• Capacities 5–100 kg
• Aluminum construction
• Single-point 400 x 400 mm platform
• OIML R60 and NTEP approved
• IP65 protection
• Available with metric and UNC threads
• Optional
❍ FM approval available
❍ IP67 available
APPLICATIONS
• Bench scales
• Counting scales
• Grocery scales
