Model 5103 Double-Ended Beam Load Cell
Discover the Model 5103 Double-Ended Beam Load Cell by Revere. Ranging from 5k to 250k lbs, with low profile, nickel-plated alloy steel, OIML R60, and NTEP CoC certifications. Ideal for platform scales, weighbridge, silo, and hopper weighing with IP67 rating
$369.15
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $364.15 |
| 11 - 15 | $10.00 | $359.15 |
| 16 - 20 | $15.00 | $354.15 |
Payment Methods:
Description
Title :- Model 5103 Double-Ended Beam Load Cell
Brand :- Revere
DESCRIPTION
Model 5103 transducers are double-ended, center-loaded shear beam load cells and are constructed of nickel plated alloy steel.
These products are suitable for tank weighing systems, low-cost weighbridges, and axle weighers.
A reliable sealing is ensured by the proprietary TRANSEAL potting compound and additional mechanical protection of the strain gage area.
A specially-designed mounting arrangement is available, providing the ideal solution for vessel / tank weighing.
FEATURES
• Capacities: 5k to 250k lbs
• Low-profile construction
• Nickel-plated alloy steel construction
• Certified to OIML R60 3000d, NTEP CoC—10000d
• Sealing: IP67 (DIN 40.050)
• Optional
– FM approved for use in hazardous locations
– ATEX & UKCA versions for use in potentially-explosive
atmospheres
– EDOC product appearance will differ from the
photograph due to coating
APPLICATIONS
• Platform scales
• On-board weighing
• Weighbridges
• Silo hopper weighing
