Model 65016-W Welded, Stainless Steel Double-Ended Shear Beam Load Cell
Sensortronics Model 65016-W Double-Ended Shear Beam Load Cell – High-capacity stainless-steel load cell, IP67 rated, FM approved, and multi-cell system compatible for tank weighing , bin weighing , silo weighing , batching, and blending applications. Welded seal with conduit adapter for harsh environments.
Price range: $171.08 through $388.08
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model 65016-W Welded, Stainless Steel Double-Ended Shear Beam Load Cell
Brand :- Sensortronics
DESCRIPTION
Model 65016-W is designed to be center-mounted with double-linked loading. This design provides free movement in all horizontal directions, virtually eliminating
binding or friction points. The double Shear Beam design gives an excellent performance for high capacity loading.
The stainless-steel construction and IP67 rating make this load cell ideal for any environmental installation.
FEATURES
• Rated capacities of 1000 to 100,000 pounds
• Stainless steel, welded seal construction
• Insensitive to side loads and bending moments
• High output—well suited to high dead load/low
live load applications
• Load cells have matched outputs for multi-cell systems
• Integral conduit adaptor
• Sensorgage™ sealed to IP67 standards
• Factory Mutual System Approved for Classes I, II, III;
Divisions 1 and 2; Groups A through G.
• Non-incendive ratings (without barriers)
• Optional
– Fully hermetically sealed version
APPLICATIONS
• Hostile environments:
Food and beverage processing
Chemical and plastics processing
Pharmaceutical and biomedical processing
• Tank, bin, and silo weighing
• Batching, blending and mixing systems
• Level and inventory monitoring
