Model 65040W Steel, Welding Sealed Double-Ended Shear Beam Load Cell
Sensortronics Model 65040W Double-Ended Shear Beam Load Cell – High-capacity stainless-steel load cell, IP68 rated, NTEP certified, and FM approved for truck scales, rail scales, and industrial weighing. Welded seal with integral conduit adapter for harsh environments.
Price range: $157.05 through $163.02
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | - |
| 11 - 15 | $10.00 | - |
| 16 - 20 | $15.00 | - |
Payment Methods:
Description
Title :- Model 65040W Steel, Welding Sealed Double-Ended Shear Beam Load Cell
Brand :- Sensortronics
DESCRIPTION
Model 65040W is a mid to high-capacity welded stainless-steel, double-ended shear beam load cell.
The product is designed for use in certified truck and rail scales and is available in capacities ranging from 25k through 75k lbs. (For higher capacities consult with
the factory.)
This load cell is rated intrinsically safe by the Factory Mutual System (FM); making it suitable for use in potentially-explosive environments. This load cell is certified for Legal for Trade applications by American NTEP standards.
FEATURES
• Rated capacities of 25,000 to 75,000 lbs.
(Higher capacities are also available)
• Welded seal, stainless-steel construction
• Center supported, external pivot loading
• Integral conduit adaptor
• Trade certified for NTEP Class IIIL: 10000 divisions
• Sensorgage™ sealed to IP68 standards
• Factory Mutual System Approved for Classes I, II, III;
Divisions 1 and 2; Groups A through G.
• Non-incendive ratings (without barriers)
APPLICATIONS
• Hostile environments:
Food and beverage processing
Chemical and plastics processing
Pharmaceutical and biomedical processing
• Truck scales
• Railroad track scales
