Model 65114 Stainless Steel, Single-Column Compression Load Cell
The Sensortronics Model 65114 Stainless Steel Compression Load Cell is a high-capacity (50k–100k lbs) single-column load cell with IP67 & IP68 sealing for outdoor & harsh environments. NTEP, OIML & FM approved, it’s ideal for truck scales, weighbridges, tank & silo weighing, and hopper weighing for heavy loads.
$560.80
| Quantity | Discount | Discounted price |
| 5 - 10 | $5.00 | $555.80 |
| 11 - 15 | $10.00 | $550.80 |
| 16 - 20 | $15.00 | $545.80 |
Payment Methods:
Description
Title :- Model 65114 Stainless Steel, Single-Column Compression Load Cell
Brand :- Sensortronics
DESCRIPTION
Model 65114 is a high capacity, stainless steel single column compression load cell.
This product is specifically designed for use in rugged outdoor environments. Made from stainless steel, IP67 welded sealing comes standard, with optional, fully hermetic, IP68 sealing available upon request. This load cell is used primarily in truck and train scales, but can just as easily be used to weigh tanks and silos.
The load cell is rated intrinsically safe by the Factory Mutual System (FM); making it suitable for use in potentially explosive environments. The load cell is certified for Legal-for-Trade applications by both American NTEP and International OIML standards.
FEATURES
• Rated capacities of 50,000 to 100,000 pounds;
25 to 50 metric tonnes
• Stainless steel, welded seal construction
• 30 feet standard cable length
• Trade certified for NTEP Class IIIL: 10000 divisions and
OIML R60 3000 divisions
• Welded Sensorgage™ sealed to IP67 standards
• Factory Mutual System Approved for Classes I, II, III;
Divisions 1 and 2; Groups A through G.
• Non-incendive ratings (without barriers)
• Optional
– Hermetically sealed version, meets IP66/68 standards
APPLICATIONS
• Truck scales
• Tank, bin, and hopper weighing
